CRANE OVERLOAD WARNING SYSTEM

Complete with audible warning device which activates in conjunction with the red LEDs.
The unit takes its inputs from the load weighing system fitted to the vehicle. When the vehicle is operating below capacity a GREEN
LED light is in operation, when the capacity is higher (dependant on vehicle specification) the GREEN LED light goes off and the AMBER LED light comes on. If the vehicle is operating in overload mode the AMBER LED light goes off and the RED LED light and ALARM alerts people in the surrounding area that the vehicle is operating in a dangerous fashion. The LED lights and ALARM can be pulsed if required – this function is normally controlled by the vehicle manufacturer.

When the AMBER light is on, the audible alarm sounds intermittently. When the RED light is on, it is continuous.

• Dual voltage 12-24V
• High powered LED lights
• E marked – e11*72/245*2009/19*7568*00
• 10R approval – 10R-037568
• Completely encapsulated to withstand vibration and shock
• Continuous tone or intermittent
• Complete with mounting screws
• Speaking versions available
• Separate in-cab warning light and buzzer available to warn the driver
• IP67 rated

Suitable for:
Vehicles where overloading warnings are required – cranes, forklifts, telehandlers, Hiabs etc…
